型号 | 转速 | 流量 | 压力 | 功率 | 重量 | 进水口 | 出水口 | ||||
| RPM | L/min | GPM | Bar | Mpa | PSI | kW | HP | kg | Thread | Thread |
FDK 3050 | 1450 | 30.0 | 7.9 | 500 | 50 | 7251 | 28.8 | 38.6 | 38.5 | G 3/4 | G 1/2 |
FDK 4035 | 1450 | 40.0 | 10.5 | 350 | 35 | 5076 | 28.0 | 37.5 | 38.5 | G 3/4 | G 1/2 |
FDK 5030 | 1450 | 50.0 | 13.2 | 300 | 30 | 4351 | 30.0 | 40.2 | 38.5 | G 3/4 | G 1/2 |
FDK 5525 | 1450 | 55.0 | 14.5 | 250 | 25 | 3625 | 27.5 | 36.8 | 38.5 | G 3/4 | G 1/2 |
FDK 3650 | 1750 | 36.0 | 9.5 | 500 | 50 | 7251 | 36.0 | 48.2 | 38.5 | G 3/4 | G 1/2 |
FDK 4835 | 1750 | 48.0 | 12.6 | 350 | 35 | 5076 | 33.5 | 44.9 | 38.5 | G 3/4 | G 1/2 |
FDK 6030 | 1750 | 60.0 | 15.8 | 300 | 30 | 4351 | 36.0 | 48.2 | 38.5 | G 3/4 | G 1/2 |
FDK 6625 | 1750 | 66.0 | 17.4 | 250 | 25 | 3625 | 33.0 | 44.2 | 38.5 | G 3/4 | G 1/2 |
